How are CNC perforated panel sale rates calculated?

The live calculator builds a transparent sale rate from aluminium (₹450/kg × weight), CNC (₹50 × standard bill sft), powder coat and install (+ optional LED ₹135/sft), with atelier margin included in the displayed estimate. Use the live calculator on this page for exact figures.

What thickness for ceiling vs elevation CNC panels?

Ceilings usually use 0.8–1.2mm. Elevations: 1.5mm for low height, 2mm recommended up to about 5 floors, or 3–4mm for high-rise. Large elevation sizes may require 2–4mm based on perforation open area.

Do you install CNC perforated panels in Hyderabad, Bengaluru and Ahmedabad?

Yes. Priority markets are Hyderabad, Bengaluru (Bangalore) and Ahmedabad, with fabrication and installation across India. Site survey available in Hyderabad; projects coordinated pan-India.

Which powder coating brands and warranty do you offer?

We powder coat with AkzoNobel and Jotun systems. Exterior coating warranty typically ranges from 10 to 25 years depending on the selected finish and exposure.

Can you make custom size and 3D CNC perforated panels?

Yes. Besides standard modules we fabricate custom size panels and 3D / formed panels from CAD drawings for elevations and feature ceilings.

Where are perforated metal ceilings used?

Bathroom ceilings, passage ceilings, ramp and parking soffits, balcony ceilings and general false ceilings — any suspended ceiling needing airflow, access and a modern perforated look.

CNC Perforated Panels — Aluminium Jaali, Perforated Metal Ceiling & LED Facade

Precision CNC-cut perforated aluminium panels for elevations, false ceilings, bathroom ducts and balconies. Custom sizes and 3D panels available. AkzoNobel & Jotun powder coat with 10–25 year coating warranty. Priority installs in Hyderabad, Bengaluru and Ahmedabad — live calculator below.

CNC perforated aluminium jaali facade cladding panels — ALLUKRAFT™ Hyderabad, Bengaluru & Ahmedabad

3 CNC Perforated Product Types — Live Calculator Prices

Hub Summary — CNC Perforated Cladding, Ceiling & LED

Perforated cladding / aluminium jaali — Elevation frame + rivets; thickness by building height. Open page →
Perforated metal ceiling — Male–female clip system; removable for service access. Open page →
Illuminated CNC with LED — Backlit facade jaali (+ ₹135/sft LED option). Open page →

For rain-proof duct ventilation with Z louvers, see also plumbing duct shaft covers.

Live Price Calculator — Ceiling & Elevation

Enter ceiling or elevation area (m), joint preference and thickness — panel size, qty and BOM auto-calculate from rates.json.

Loading pricing...

What drives your live estimate

The calculator is transparent atelier pricing — aluminium, CNC, powder coat and install are shown as separate line drivers so architects and owners can see what shapes the sale rate before a site survey.

Component	Rate basis
Aluminium sheet	₹450 / kg + GST · weight = 0.25 kg/sft × mm
CNC cutting	₹50 / sft on standard billing size
Powder coat	Plain ₹25 · Texture ₹30 · Wooden ₹45 / sft
Ceiling install	₹80 / sft
Elevation frame	50×50×1.5 ₹120 · 50×100×1.5 ₹180 / sft
LED (optional)	₹135 / sft
Displayed sale rate	Live estimate includes atelier margin — see calculator summary for your panel set

Install Systems at a Glance

Ceiling — clip system

Male–female clipping — fast, strong, removable
Pull any panel for services behind; push back to refit
Any drop / gap from main ceiling
Threaded rods + GI channels · stable in open / fresh air

Elevation — frame & rivets

Aluminium or iron frame
50×50×1.5mm or 50×100×1.5mm pipe + GI brackets
Anchor bolts · same-coating aluminium rivets (12mm head)
6–8mm holes for thermal movement · ~200mm rivet spacing

Applications — Elevation, Ceiling, Bathroom Ducts & Balcony

Building elevations — CNC perforated cladding and aluminium jaali for commercial buildings and luxury villas
Perforated metal ceilings — Bathroom, passage, ramp, parking, balcony and general false ceilings
Bathroom / plumbing duct covers — Ventilated perforated covers on service shafts (pair with Z louvers when rain-proofing is critical)
Balcony screens — Privacy jaali with airflow and modern pattern options
Custom & 3D panels — Non-standard sizes and formed panels from CAD

How We Fabricate & Install CNC Perforated Panels

Every CNC commission follows the same atelier workflow used across railings, louvers and pergolas — measured on site, cut in-house, coated to brand systems, then installed by the team that fabricated it. See Our Process for the full six-step commission flow.

Site survey — Confirm elevation height, ceiling drop, duct openings and joint preference (visible vs tight).
Size & module layout — Match panel size, thickness and perforation % to span and wind exposure; custom and 3D panels from CAD when needed.
CNC fabricate — Cut aluminium to pattern; weight guide 1mm sheet = 0.25 kg/sft; ceiling fabrication ≈ 0.20 kg/sft.
Powder coat — AkzoNobel or Jotun systems in plain, texture or wood-look.
Install — Ceiling clip system (rods + GI channels) or elevation frame with anchor bolts and thermal-safe rivets.

Why Specify ALLUKRAFT™ CNC Panels

ALLUKRAFT™ is a Hyderabad atelier with 26 years of craft in architectural aluminium and glass — we design, CNC-cut, coat and install perforated panels ourselves, not through anonymous job shops. About the atelier.

Manufacturer–installer accountability — One team owns survey, fabrication, coating and fixing.
Height- and use-matched specs — Ceiling gauges (0.8–1.2mm) vs elevation thickness by floors; large panels only with correct thickness and open-area rules.
Service-friendly systems — Removable ceiling clips; elevation rivets sized for thermal movement.
Transparent live calculator — Sale rates from documented aluminium, CNC, coat and install drivers — no opaque lump sums.
Related systems in-house — Pair jaali with duct shaft Z louvers or profile louvers when the elevation needs both.

Coating & Warranty — AkzoNobel & Jotun

Exterior and interior finishes use AkzoNobel and Jotun powder coating systems. Typical coating warranty is 10–25 years depending on colour, gloss and site exposure. Plain, texture and wooden finishes are selectable in the live calculator.

Full coverage terms: Warranty & Guarantee. Transparent atelier pricing context: Atelier Pricing.

Where We Install — CNC Perforated Panels

Priority installs: Hyderabad, Bengaluru (Bangalore) and Ahmedabad, with pan-India fabrication and installation support from our Hyderabad atelier.

Hyderabad — Atelier base; villa and commercial elevations, bathroom duct covers, parking and passage ceilings surveyed and installed locally.
Bengaluru — High-rise and villa jaali cladding, illuminated entrance features and perforated false ceilings for IT / residential projects.
Ahmedabad — Commercial elevations and luxury villa screens with thickness matched to height and heat.

Site survey in Hyderabad; projects coordinated pan-India. WhatsApp drawings or site photos for a pattern recommendation and live sale-rate estimate.

Frequently Asked Questions — CNC Perforated Panels

How are CNC perforated panel sale rates calculated?	The live calculator builds a transparent sale rate from aluminium (₹450/kg × weight), CNC (₹50 × standard bill sft), powder coat and install (+ optional LED ₹135/sft), with atelier margin included in the displayed estimate. Use the calculator on this page for exact figures.
What thickness for ceiling vs elevation CNC panels?	Ceilings usually use 0.8–1.2mm. Elevations: 1.5mm for low height, 2mm recommended up to about 5 floors, or 3–4mm for high-rise. Large elevation sizes may require 2–4mm based on perforation open area.
Do you install CNC perforated panels in Hyderabad, Bengaluru and Ahmedabad?	Yes. Priority markets are Hyderabad, Bengaluru (Bangalore) and Ahmedabad, with fabrication and installation across India. Site survey available in Hyderabad; projects coordinated pan-India.
Which powder coating brands and warranty do you offer?	We powder coat with AkzoNobel and Jotun systems. Exterior coating warranty typically ranges from 10 to 25 years depending on the selected finish and exposure.
Can you make custom size and 3D CNC perforated panels?	Yes. Besides standard modules we fabricate custom size panels and 3D / formed panels from CAD drawings for elevations and feature ceilings.
Where are perforated metal ceilings used?	Bathroom ceilings, passage ceilings, ramp and parking soffits, balcony ceilings and general false ceilings — any suspended ceiling needing airflow, access and a modern perforated look.

Get a Quote — CNC Perforated Panels in Hyderabad, Bengaluru & Ahmedabad

Share elevation drawings or ceiling area for a pattern recommendation and live sale rate. WhatsApp or call for site survey at our Hyderabad atelier; projects across India. Contact · About the atelier.
